Battery heating sleeves available in 70W, 100W, 130W and 160W configurations, with 120V and 240V options for different battery circumferences.
The Stallion Battery Heating Sleeve is designed to wrap around a compatible battery and provide electrical heating in low-temperature conditions. The range includes four sleeve sizes and power ratings, allowing the appropriate model to be selected according to battery circumference, available voltage and required heating capacity.
The product range is available in 70W, 100W, 130W and 160W configurations. Each size is offered in both 120V and 240V versions. Depending on the selected model, the sleeves are suitable for battery circumferences ranging from approximately 785mm to 1830mm.
Each Battery Heating Sleeve includes built-in temperature control set at approximately 27°C with a tolerance of ±1.5°C, together with high-temperature protection at 32°C. All listed models have an IP65 protection rating, an operating temperature range of -30°C to 55°C and a storage temperature range of -40°C to 80°C. The external power cable is approximately 1.5 metres long and is listed with an American-standard power plug.
The Stallion Battery Heating Sleeve range offers multiple power ratings, voltage options and sleeve dimensions for different battery-circumference requirements.
The range includes 70W, 100W, 130W and 160W models for different battery-circumference and sleeve-size requirements.
The temperature-control setting is approximately 27°C with a stated tolerance of ±1.5°C.
All Battery Heating Sleeve models listed in the catalogue have an IP65 protection rating.
Available models cover battery circumferences from approximately 785mm to 1830mm.
The listed operating-temperature range is -30°C to 55°C, with a storage-temperature range of -40°C to 80°C.
The external power cable is approximately 1.5 metres long and is listed with an American-standard power plug.
Technical specifications vary according to the selected sleeve size and voltage configuration.
Request Full Datasheet| Models | STAC0071, STAC0072, STAC0101, STAC0102, STAC0131, STAC0132, STAC0161, STAC0162 |
| Rated Voltage | 120V and 240V configurations |
| Rated Power | 70W, 100W, 130W and 160W |
| Rated Current | 0.29A to 1.33A |
| Sleeve Dimensions | 965 × 192mm to 1880 × 192mm |
| Battery Circumference | 785mm to 1830mm |
| Temperature Control | 27°C ±1.5°C |
| High-Temperature Protection | 32°C |
| Protection Level | IP65 |
Select the appropriate Battery Heating Sleeve according to battery circumference, available voltage, sleeve dimensions and required power rating.
Available in 120V and 240V versions for battery circumferences from approximately 785mm to 915mm.
Available in 120V and 240V versions for battery circumferences from approximately 1090mm to 1220mm.
Available in 120V and 240V versions for battery circumferences from approximately 1395mm to 1525mm.
Available in 120V and 240V versions for battery circumferences from approximately 1700mm to 1830mm.
Four 120V Battery Heating Sleeve models are available across the complete 70W to 160W power range.
Four 240V Battery Heating Sleeve models are available across the complete 70W to 160W power range.
